A LCR circuit behaves like a damped harmonic oscillator. Comparing it with a physical springmass damped oscillator having damping constant ‘b’ the correct equivalence would be
Select the correct option:
A
$L \leftrightarrow m, C \leftrightarrow \frac{1}{k}, R \leftrightarrow b$
B
$L \leftrightarrow k, C \leftrightarrow b, R \leftrightarrow m$
C
$L \leftrightarrow \frac{1}{b}, C \leftrightarrow \frac{1}{m}, R \leftrightarrow \frac{1}{k}$
D
$L \leftrightarrow m, C \leftrightarrow k, R \leftrightarrow b$
